Item

Test Condition

Unit&Symbol

95%Alumina ceramics

99%Alumina ceramics

99.7%Alumina ceramics

The main chemical ingredient

Al2O3

Al2O3

Al2O3

Bulk Density

g/cm3

3.6

3.89

3.96

Maximum Use Temperature

1450°C

1600°C

1650°C

Water absorption

%

0

0

0

ROHS Hardness

≥85

≥89

≥89

Flexural strength

20° C

MPa (psi x 10³)

358 (52)

550

550

Compressive Strength

20° C

MPa (psi x 10³)

2068 (300)

2600(377)

2600(377)

Fracture Toughness

K(I c)

Mpa m^1/2

4-5

5.6

6

Coefficient of

thermal expansion

25-1000° C

1X 10^-6/°C

7.6

7.9

8.2

Coefficient of

thermal conductivity

20° C

W/m °K

16

30.0

30.4

Thermal Shock Resistance

Tc

°C

250

200

200

Dielectricity constant

1MHz.25°C

9

9.7

9.7

Dielectric strength

ac-kV/mm (ac V/mil)

8.3 (210)

8.7 (220)

8.7 (220)

Volume Resistivity

100°C

ohm-cm

> 10¹³

> 10¹⁴

> 10¹⁴

Feature

Application

Main usage

1.Great mechanical strength

Electric appliance industry

Automotive industry

1.Heat treatment furnace

and toughened furnace

2.High softening temperature

3.Good resistance

to thermal impact

4.Small thermal expansion

 coefficient

Mechanical industry

Engineer industry

2.Inner liner tube and heating

tube in electric furnace

5.Good chill and abrupt

heat properties

6. Resistance to acid and

 alkali corrosion
